Engine and Drive Train | |
---|---|
Cylinders | 1 |
Strokes | 4-Stroke |
Valves per cylinder | 4 |
Cooling | liquid |
Displacement | 125 ccm |
Bore | 52,4 mm |
Stroke | 54,9 mm |
Max. Power Output | 14,5 HP |
Rpm at Max. Power Output | 9250 rpm |
Max. Torque | 12 Nm |
Rpm at Max. Torque | 8000 rpm |
Compression Ratio | 11,5 |
Starter | Electric |
Clutch Type | Centrifugal force |
Ignition | Digital, Transistor |
Final Drive | Belt |
Transmission Type | Variomatic |
Chassis | |
Frame | Steel |
Suspension Rear | |
Rear suspension | Unit Swing |
Brakes Front | |
Piston | Double piston |
Brakes Rear | |
Rear brake | Disc |
Piston | Single piston |
Dimensions and Weights | |
Front tyre width | 120 mm |
Front tyre height | 70 % |
Front tyre diameter | 15 inch |
Rear tyre width | 140 mm |
Rear tyre height | 70 % |
Rear tyre diameter | 14 inch |
Length | 2134 mm |
Width | 748 mm |
Height | 1452 mm |
Wheelbase | 1490 mm |
Seat Height from | 780 mm |
Kerb Weight (with ABS) | 162 kg |
Fuel Tank Capacity | 11,5 l |
License | A1 |
All information is supplied without guarantee. Errors and clerical errors reserved.
