Engine and Drive Train | |
---|---|
Cylinders | 1 |
Strokes | 4-Stroke |
Cooling | liquid |
Displacement | 149,7 ccm |
Bore | 66 mm |
Stroke | 43,8 mm |
Max. Power Output | 23,8 HP |
Rpm at Max. Power Output | 12500 rpm |
Max. Torque | 14,1 Nm |
Rpm at Max. Torque | 11000 rpm |
Compression Ratio | 11,7 |
Starter | Kick |
Ignition | CDI |
Final Drive | Chain |
Chassis | |
Frame | Steel |
Frame type | Double cradle |
Suspension Front | |
Front suspension | Upside-Down telescopic fork |
Brand | Showa |
Adjustment | Compression, Rebound |
Suspension Rear | |
Brand | Showa |
Adjustment | Compression, Rebound |
Brakes Front | |
Piston | Single piston |
Brakes Rear | |
Rear brake | Disc |
Piston | Single piston |
Dimensions and Weights | |
Front tyre width | 70 mm |
Front tyre height | 100 % |
Front tyre diameter | 19 inch |
Rear tyre width | 90 mm |
Rear tyre height | 100 % |
Rear tyre diameter | 16 inch |
Length | 1900 mm |
Width | 770 mm |
Height | 1171 mm |
Wheelbase | 1285 mm |
Seat Height from | 866 mm |
Kerb Weight | 84,4 kg |
Fuel Tank Capacity | 4,3 l |
License | A2 |
All information is supplied without guarantee. Errors and clerical errors reserved.
