Engine and Drive Train | |
---|---|
Cylinders | 1 |
Strokes | 4-Stroke |
Valves | OHC |
Cooling | Air |
Displacement | 124,9 ccm |
Bore | 52,4 mm |
Stroke | 57,9 mm |
Max. Power Output | 9 HP |
Rpm at Max. Power Output | 7000 rpm |
Max. Torque | 10,2 Nm |
Rpm at Max. Torque | 4500 rpm |
Compression Ratio | 9,5 |
Starter | Kick |
Ignition | CDI |
Final Drive | Chain |
Chassis | |
Frame | Steel |
Frame type | Backbone |
Brakes Rear | |
Rear brake | Drum |
Dimensions and Weights | |
Front tyre width | 70 mm |
Front tyre height | 100 % |
Front tyre diameter | 17 inch |
Rear tyre width | 90 mm |
Rear tyre height | 100 % |
Rear tyre diameter | 14 inch |
Length | 1770 mm |
Width | 740 mm |
Height | 1010 mm |
Wheelbase | 1220 mm |
Seat Height from | 735 mm |
Kerb Weight | 88 kg |
Fuel Tank Capacity | 4,3 l |
License | A1 |
All information is supplied without guarantee. Errors and clerical errors reserved.
